RS-W716AHBB97A 6MP Human & Vehicle Detection IR Turret IP Camera
Features:
- 1/2.8" Sony CMOS sensor
- Max. 6MP resolution 3072x2048
- Low illumination 0.01Lux
- Day/Night, AWB/MWB,BLC, HLC, 2D/3D-DNR,Shutter, IR-CUT
- D-WDR,Mirror, rotate, Defogging
- Multiply Style OSD Overlay,Motion Detection, Privacy Mask
- RTSP and Onvif 17.06 compatible with many third-party NVR
- H.264/H.265 dual-stream media server
- Easy-to-use P2P Cloud service
- Support user authentication, video data encryption
- Support Alarm Snapshot to Email and FTP
- Multiply WEB browser IE,Firefox 32bit ESR, PC Client, Mobile APP remote access
- RJ45 100mbps network port, IEEE802.3af PoE
- Lightning protection 4000V
- Strong water-proof housing, IP66
- 18 pcs SMD IR Led, IR distance 30 meters
- HD 3.6mm fix lens
- Support Human body detection,vehicle detection
Technical Specifications:
|
Model |
YC-W716AHBB97A |
|
Camera |
|
|
1/2.8" Sony CMOS |
|
|
Effective Pixels |
3072(H)×2048 (V) |
|
Electronic Shutter |
AUTO, 1/25s ~ 1/100000s |
|
Min. Illumination |
0.01Lux@F1.2(AGC ON), 0Lux IR on |
|
Day/Night |
Auto/Color/(B/W)/Timing |
|
WDR |
Digital WDR |
|
White Balance |
Auto/Manual |
|
AGC/BLC/HLC |
Support |
|
DNR |
2D/3D DNR |
|
Other |
Multi-lines OSD, Motion Detection, Privacy Mask, Mirror |
|
Encode |
|
|
Video Standard |
H.264/H.265 |
|
Video Resolution |
Main Stream: Sub stream: 30fps@D1/VGA/360P/CIF, etc. |
|
Video Bitrates |
64Kbps - 8Mbps, VBR/CBR |
|
Audio Standard |
G.711-u/G.711-a/AAC |
|
Built-in Mic |
Yes |
|
Smart Event |
Human Detection Vehicle Detection |
|
IR Led |
|
|
IR Led |
18 pcs SMD IR Leds |
|
IR Distance |
20-30 M |
|
Lens |
|
|
Focal length |
2.8/3.6 mm fixed |
|
Optional Function |
|
|
POE, Audio, etc. |
|
|
Network Services |
|
|
Protocol |
HTTP(S)/RTSP/RTMP/FTP/NFS/SMTP/DHCP/NTP, etc. |
|
P2P |
Yes |
|
Web |
IE , Firefox 32bit ESR, etc. |
|
Media |
CMS, Android, IOS |
|
ONVIF |
17.06 compatible |
|
General |
|
|
Network Port |
1-RJ45, 100Mbps, POE optional |
|
Power Supply |
12 VDC ± 10% |
|
Power Consumption |
< 5 W |
|
Operating Temp. |
-30℃-(+60)℃, 10%-90%RH |
